Description
Input
• Maximum PV Array Power: 3000Wp / 6000Wp
• Maximum DC Voltage: 550V
• Nominal DC Operating Voltage: 360V
• Maximum Input Current: 11A / 22A
• Maximum Short Circuit Current: 12A / 24A
• MPPT Voltage Range: 100V – 530V
• Start Operating Voltage: 120V
• Number of MPP Trackers: 2
• Strings per MPP Tracker: 1/2
Output AC
• Nominal AC Power: 8000VA
• Maximum AC Power: 8000VA
• Nominal Grid Voltage(AC): 220V/230V/240V; 160V to 285V
• Nominal Grid Frequency Range: 50Hz/60Hz; ±5
• Nominal AC Current: 35A
• Maximum AC Current: 45A
• Displacement Power Factor: 0.8 leading ~ 0.8 lagging
• THDi, rated power: <3%
Environment Limit
• Ingress Protection: IP65
• Operating Temperature Range: -25°C to +60°C (derating at 45°C)
• Maximum Operation Altitude: 2000m
• Humidity: 0% to 100% (Non Condensing)
• Storage Temperature: -25°C to +60°C
• Communication: Pocket WIFI/Pocket LAN/Pocket GPRS/Meter/RS485/DRM/USB-Upgrade
• Certification: IEC62109-1 / IEC62109-2 / AS4777
