Description
Input (DC)
• Maximum PV Array Input Power: 10000Wp
• Maximum PV Input Voltage: 600V
• Nominal DC Operating Voltage: 360V
• Maximum Input Current: 14A / 14A
• Maximum Short Circuit Current: 16A / 16A
• MPPT Voltage Range: 70V – 550V
• Start Operating Voltage: 60V
• Number of MPP Trackers: 2
• Strings per MPP Tracker: 1/1
AC Input & Output
• Nominal AC Output Power: 7500W
• Nominal AC Output Current: 32.6A
• Maximum AC Output Apparent Power: 7500VA
• Maximum AC Output Current: 32.6A
• Maximum AC Input Apparent Power: 9200VA
• Maximum AC Input Current: 40A
• Nominal AC Voltage: 220V/230V/240V
• Nominal Grid Frequency Range: 50Hz/60Hz
• Displacement Power Factor: 0.8 leading ~ 0.8 lagging
• THDi, rated power: <2%
Environment Limit
• Ingress Protection: IP65
• Operating Temperature Range: -35°C to +60°C (derating at 45°C)
• Maximum Operation Altitude: <3000m
• Humidity: 0% to 100% (Non Condensing)
• Storage Temperature: -40°C to +70°C
• Communication: CT/Meter/External Control RS485/Pocket Series/DRM/USB Upgrade
• Certification: IEC62109-1 / IEC62109-2 / AS4777
