Description
Input (DC)
• Maximum PV Array Input Power: 13000Wp
• Maximum DC Voltage: 1000V
• Nominal DC Operating Voltage: 720V
• Maximum Input Current: 24A / 12A
• Maximum Short Circuit Current: 28A / 14A
• MPPT Voltage Range: 180V – 950V
• Start Operating Voltage: 180V
• Number of MPP Trackers: 2
• Strings per MPP Tracker: 2/1
AC Input & Output
• Nominal AC Power: 10000VA
• Maximum Apparent AC Power: 11000VA
• Nominal Grid Voltage: 400VAC/230VAC ; 380VAC/220VAC
• Nominal Grid Frequency Range: 50Hz/60Hz
• Nominal AC Current: 14.5A
• Maximum AC Current: 15.9A
• Displacement Power Factor: 0.8 leading ~ 0.8 lagging
• THDi, rated power: <3%
Environment Limit
• Ingress Protection: IP65
• Operating Temperature Range: -20°C to +60°C (derating at 45°C)
• Maximum Operation Altitude: <2000m
• Humidity: 0% to 100% (Condensing)
• Storage Temperature: -20°C to +60°C
• Communication: Ethernet/Meter/Pocket Interface/DRM/USB/CAN/BMS/NTC
• Certification: IEC62109-1 / IEC62109-2 / AS4777
