Description
Input (DC)
• Maximum PV Array Input Power: 22500Wp
• Maximum DC Voltage: 1000V
• Nominal DC Operating Voltage: 600V
• Maximum Input Current: 12A / 24A
• Maximum Short Circuit Current: 14A / 28A
• MPPT Voltage Range: 160V – 850V
• Start Operating Voltage: 180V
• Number of MPP Trackers: 2
• Strings per MPP Tracker: 1/2
AC Input & Output
• Nominal AC Power: 15000VA
• Maximum Apparent AC Power: 16500VA
• Nominal Grid AC Voltage: 3/N/PE 230VAC/400VAC(310VAC-480VAC)
• Nominal Grid Frequency Range: 50Hz/60Hz ±5Hz
• Nominal AC Current: 21.7A
• Maximum AC Current: 23.9A
• Displacement Power Factor: 0.8 leading ~ 0.8 lagging
• THDi, rated power: <3%
Environment Limit
• Ingress Protection: IP65
• Operating Temperature Range: -25°C to +60°C (derating at 45°C)
• Maximum Operation Altitude: <2000m
• Humidity: 0% to 100% (Condensing)
• Storage Temperature: -25°C to +60°C
• Communication: RS485/DRM/Pocket Interface/Meter/USB Upgrade
• Certification: VDE4105, AS4777, EN50549, IEC61727
